Patton electronics SmartNode Series Software Configuration Manual page 170

14 • Link scheduler configuration
The command has optional values (in the range of 1 to 4) that define the level of detail (see
Note The debug features offered by SmartWare require the CPU resources of your
SmartNode. Therefore do not enable statistic gathering or other debug fea-
tures if it is not necessary. Disable any debug feature after use with the no
form of the command.
You can enable queue statistica for all queues of a link scheduler by placing the debug queue statistics com-
mand in the profile header. Queue statistics are reset whenever the configuartion is changed or SmartWare is
reloaded.
Mode: Source
Step
1 node (src)[ name ]#debug queue statistics level Enables statistic gathering for the selected class
Example: Enable statistics gathering for all queues of a profile
The following example shows how to enable statistic gathering for alll traffic-classes
SN>enable
SN#configure
SN(cfg)#profile service-policy sample
SN(pf-srvpl)[sample]#debug queue statistics 4
168
Table 10. Values defining detail of the queuing statistics
Optional Value Implication on Command Output
0 Statistic gathering is switched off
1 Display amount of packets passed (did
no thave to wait), queued (arrived ear-
ler than rate permitted) and discarded
2 Also collects byte counts for the catego-
3 Also keeps track of the peek queue
lengths ever reached since the last con-
4
Command
SmartWare Software Configuration Guide
(due to overflowing queue)
ries listed above
figuration change or reload
Adds delay time monitoring
or policy name . The optional argument level ,
which is in the range from 1 to 4, defines the ver-
bosity of the command output.
table 10).
Purpose
Link scheduler configuration task list
