SmartWare Software Configuration Guide
Example: Enabling fastconnect
The following example shows how to enable the fastconnect procedure on an already defined H.323 Gateway.
SN(cfg)#gateway h323 h323
SN(gw-h323)[h323]#faststart

Enabling the early H.245 procedure

If the early H.245 procedure is enabled, the H.245 connection is opened as soon as possible instead of waiting
for the call signaling connect message. Early H.245 is disabled by default. If enabled, it only takes place when
both parties agree. The early H.245 procedure can be enabled using the following procedure:
Mode: Gateway H.323
Step
1
node (gw-h323)[h323]#early-h245
Example: Enabling early H.245
The following example shows how to enable early H.245 on an already defined H.323 Gateway.
SN(cfg)#gateway h323 h323
SN(gw-h323)[h323]#early-h245

Changing the TCP port for inbound call-signaling connections

The default TCP listening port for inbound call-signaling connections is per default 1720 as defined in the
H.323 standard. The following procedure describes how to change the port number.
Mode: Gateway H.323
Step
1
node (gw-h323)[h323]#call-signaling-port
port
Example: Defining an alternate call-signaling port
The following example shows how to define an alternate call-signaling port on an already defined H.323 Gate-
way.
SN(cfg)#gateway h323 h323
SN(gw-h323)[h323]#call-signaling-port 1721

Setting the response timeout

Per default the H.323 gateway waits for 12s from the time it initiated a call towards the IP network until it ter-
minates the call, if no response has been received. This time can be changed using the following procedure:
Mode: Gateway H.323
Step
1
node (gw-h323)[h323]# timeout response
seconds
Gateway configuration task list
Command
Command
Command
38 • H.323 gateway configuration
Purpose
Enables the early H.245 procedure.
Purpose
Define the TCP port to use for inbound call-sig-
naling connections
Purpose
Defines the response timeout in seconds.
461
