SmartWare Software Configuration Guide
Note Verify that the busy and release tones are correctly configured for the country
where the SmartNode is installed (see chapter 34,
page 417 for configuration information. If the tones are improperly config-
ured, the FXO port will not detect them, resulting in missed phone calls.
Mode: Interface FXO
Step Prompt, command & response
1 node>
2 node>enable
node#
3 node#configure
node(cfg)#
4 node(cfg)#context cs
node(ctx-cs)[switch]#
5 node(ctx-cs)[switch]#interface fxo if-name
node(if-fxo) [if-name] #
node(if-fxo) [if-name] #[no] disconnect-signal
6
{battery-reversal | busy-tone | loop-break}
Configuring how to detect an outgoing call is connected (optional)
An FXO interface has the following methods for verifying the connection of an outgoing call after the dialing
has been completed:
• Detect battery reversal (if provided by the FXS switch)
• Detect the first tax pulse (if provided by the FXS switch)
Note
Tax Impulse Signals: European telephone companies in Austria, Belgium,
Czechoslovakia, Germany, Spain and Switzerland place a pulse signal on the
phone line to meter the length of the telephone call for billing purposes.
The command to enable or disable these methods is connect-signal. If both are enabled, only one needs to
occur for the FXO interface to verify a properly connected call with the remote party. Should both be disabled,
the SmartNode waits for the call-connect signal from the FXS switch.
FXO interface configuration task list
30 • FXO interface configuration
"Tone configuration"
Purpose
Basic prompt in Operator Exec mode
Enters Administration execution mode
Response: The prompt in administration exe-
cution mode is the #
Enters the Configure configuration mode
Response: The prompt in the Configure con-
figuration mode is (cfg)#
Enters the Context CS configure mode
Response: The prompt in the Context CS con-
figuration mode is (ctx-cs)[switch]#
Enter the Interface FXO configuration mode
Response: The prompt in the Interface FXO
configuration mode is (if-fxo) [if-name] #
The default is Loop-break. To disable it, use
the no inverse command. Should all three
methods be disabled, the call is cleared 30
seconds after receiving the disconnect signal.
The default setting of loop-break is not dis-
played in the running-config output.
on
343
