33 • Call router configuration

Create a routing table

A routing table forwards the call to another table, interface or service based on a specific call property like the
called party number or the current date. The call router provides a number of different routing table types. A
routing table looks like the following:
Each table contains a header and one or more entries. The header declares the type of the routing table as well
as its name.
The name of the routing table is unique inside the context and serves as identifier for referencing the table
from other tables or interfaces. The routing table type specifies which call property the table shall examine. The
following call properties can be used as a routing table type:
Type
called-e164
calling-e164
called-type-of-number Route calls based on the called party number type. ISDN distinguishes different type of
calling-type-of-number Route calls based on the calling party number type. ISDN distinguishes different type of
called-numbering-plan Route calls based on the called party numbering plan. ISDN distinguishes different
calling-numbering-plan Route calls based on the calling party numbering plan. ISDN distinguishes different
called-name
calling-name
called-ip
370
Figure 63. Routing table outline
Table 16. Routing table types
Route calls based on the called party E.164 number. Entries of called-e164 tables can
use wildcards to summarize routes. Digit collection can be configured on a per-entry
basis.
Route calls based on the calling party E.164 number. Entries of calling-e164 tables can
use wildcards to summarize routes.
numbers.
numbers.
numbering plans.
numbering plans.
Route calls based on the display name of the called party.
Route calls based on the display name of the calling party.
Route calls based on the signaling IP address of the destination VoIP peer.
SmartWare Software Configuration Guide
Description
Call router configuration task list
