SmartWare Software Configuration Guide
• interrogate-cw—Detects whether or not the call-waiting supplementary service is active on the interface
that uses the precall service table.
Note
Currently you can only use precall service tables on FXS interfaces.
Procedure: To create precall service table and use it on an FXS interface
Mode: Context CS
Step
1
node (ctx-cs)[switch]#precall-service-
table table-name
2
node (pcs-tab)[ table-name ]#map special-
number to command
3
4
node (pcs-tab)[ table-name ]#exit
5
node (ctx-cs)[switch]#interface fxs if-name Enters FXS Interface Configuration Mode of inter-
6
node (if-fxs)[ if-name ]#use mapping-
table precall-service table-name
Example: Create and use a precall service table
The following example shows how to create a precall service table that treats *43# as activation command for
the call-waiting supplementary service, while #43# is used to deactivate call-waiting and *#43# is used to query
the call-waiting supplementary service:
SN(ctx-cs)[switch]#precall-service-table SUPP-SVC
SN(pcs-tab)[SUPP-SVC]#map *43# to activate-cw
SN(pcs-tab)[SUPP-SVC]#map #43# to deactivate-cw
SN(pcs-tab)[SUPP-SVC]#map *#43# to interrogate-cw
SN(pcs-tab)[SUPP-SVC]#exit
SN(ctx-cs)[switch]#interface fxs IF-PHONE
SN(if-fxs)[IF-PHONE]#use mapping-table precall-service SUPP-SVC
SN(if-fxs)[IF-PHONE]#exit
SN(ctx-cs)[switch]#
Configuring the precall service tables
Command
27 • CS interface configuration
Purpose
Creates a new table that maps special numbers into
supplementary service invocation commands
Adds a new entry to map a special-number into a
supplementary service invocation command .
Repeat Step 2 to add other special number map-
pings.
Returns to context CS Configuration Mode
face if-name
Uses the precall service table created with step 1 to
4 on this FXS interface.
