Preparation
Power Supply
100V type : Single phase,
(A to C-frame)
200V type : Single/3-phase, 200V
(A to D-frame)
200V type : 3-phase,
(E, F-frame)
400V type : 3-phase,
(1) This product is designed to be used in over-voltage category (installation category) III
of EN 61800-5-1:2007.
(2) Use an insulated power supply of DC12 to 24V which has CE marking or complies
with EN60950.
Circuit Breaker
Install a circuit breaker which complies with IEC Standards and UL recognized (Listed
and
The short-circuit protection circuit on the product is not for protection of branch circuit.
The branch circuit should be protected in accordance with NEC and the applicable local
regulations in your area.
Noise Filter
Option part No.
DV0P4170
DV0PM20042
DV0P4220
DV0PM20043
DV0P3410
• Recommended components
RTHN-5010
RTHN-5030
RTHN-5050
Remarks
• Select a noise filter whose capacity is commensurate with the power source capacity (in
consideration of the load condition).
• For the detailed specifications of each noise filter, contact the manufacturer.
Remarks
When performing withstand voltage test of machine and equipment, be sure to remove the
surge absorber; otherwise, it will be damaged.
Related page
• P.2-6 "Driver and List of Applicable Peripheral Equipments"
• P.7-77 "Option"
2-4
1. Conformance to international standards
Composition of Peripheral Equipments
marked) between power supply and noise filter.
Voltage specifications
for driver
Single phase 100V/200V
3-phase 200V
Single phase 100V/200V
3-phase 200V
Single/ 3-phase 200V
3-phase 200V
3-phase 200V
Voltage specifications
Model No.
for driver
3-phase 200V
+10%
100V to 120V
–15%
+10%
to 240V
–15%
+10%
200V to 230V
+10%
380V to 480V
–15%
Manufacturer's
part No.
SUP-EK5-ER-6
3SUP-HU10-ER-6
3SUP-HU30-ER-6
3SUP-HU50-ER-6
3SUP-HL50-ER-6B
Applicable driver
(frame)
A, B, C-frame
D-frame
E, F-frame
+10%
50/60Hz
–15%
+10%
50/60Hz
–15%
+10%
50/60Hz
+10%
50/60Hz
–15%
Applicable
Manufacturer
driver (frame)
A and B-frame
A, B-frame
C-frame
Okaya Electric Ind.
D-frame
E-frame
F-frame
Manufacturer
TDK-Lambda Corp.
