Introduction; Outline; On Opening The Product Package; Motor - Panasonic MINAS A5-series Operating Instructions Manual

1
Before Using
the Products
The AC Servo Motor & Driver, MINAS A5-series is the latest servo system that meets all
demands from a variety of machines which require high speed, high precision and high
performance or which require simplified settings.
Compared with the preceding A-series, product of A5-series offers superior performance
while requiring simple setup and adjustment by the user.
Newly designed motors have wide range of outputs from 50 W to 5.0 kW, associated with
20-bit incremental encoder and reduced cogging torque.
They are compatible with 2 closed controls (serial communication type and A-/B-phase
output type) and provided with various automatic adjusting functions such as real time
auto tuning with many automatic setting parameters to make complex tuning easy.
These motors assure higher stability with low stiffness machine and high-speed, high
accurate operation with high stiffness machine. They can be used in combination with a
wide variety of machines.
This manual is written as a complete guide for you so that you can fully and correctly
make use of all functions available from MINAS A5.
1
Before Using
the Products
• Make sure that the model is what you have ordered.
• Check if the product is damaged or not during transportation.
• Check if the Operating Instructions (safety) are included or not.
• Check if the power connector, motor connectors, connector for external regenerative
resistor connection (only E-frame) and safety by-pass plug are included or not.
(Neither the power connector nor motor connector are included to F-frame.)
1-2

1. Introduction

Outline

1. Introduction

On Opening the Product Package

Contact to a dealer if you find any failures.
