Simrad SH90
176

Zoom Scale

Dialog description
The
parameter dialog opens when you click the
Zoom
button in the
VerticalView
This parameter dialog is used for scaling the zoom around the
bottom.
Zoom Scale dialog options
•
: Click to select zoom scale.
[x] %
•
: Click to close the parameter dialog.
Close
•
: Click to access the on-line help.
Help
Related topics
•
VerticalView menu on page 111
menu.
Zoom
323775/A
