4. Press [Esc] to exit.

4.2.4 Set the Internal Resistance

This series instrument provides internal resistance setting (CV priority mode
only). The procedures are shown as below.
1. Press the composite keys [Shift] + [V-set] (Config) on the front panel to
enter the config menu.
2. Press the up/down key or rotate the knob to find Output Resistance menu.
i.
3. Press [Esc] to exit.

4.2.5 Set the Output-On/Output-Off Delay

You can set the output-on/output-off delay time within the range from 0 seconds
to 60 seconds.

On Delay+Offset: Indicates from the time that a command to turn on the
output is received until the output actually turns on.

Off Delay+Offset: Indicates from the time that a command to turn off the
output is received until the output actually turns off.
The procedures to set the output delay time are as follows.
1. Press the composite keys [Shift] + [V-set] (Config) on the front panel to
enter the config menu.
2. Press the up/down key or rotate the knob to find Onoff Delay menu.
i.
ii.
3. Press [Esc] to exit.

4.2.6 Enable the Output

User can control the output switching of the instrument's 2 channels by pressing
the [CH1 On/Off] key and the [CH2 On/Off] key on the front panel. When
receive the On/Off command, the instrument enable or disable the output
according to the On/Off delay time. If the On/Off delay time set to 0, the source
enable or disable output immediately. Detailed information of On/Off delay time
refers to

When [On/Off] key is lit, indicates the output is enabled, the LCD displays
source present run mode.

When [On/Off] key is lit, indicates the output is disabled, the LCD displays
source state is OFF.

4.3 Protection Function

Press [Shift]+[Recall] (Protect) and enter to Protect configure menu, where
you can set the following protection.
Over Voltage Protection
Press the up/down key to move the cursor to the Level function setting
and press the [Enter] key to confirm. Use the numeric keys to set the
internal resistance value and press [Enter] to confirm.
Press the up/down key to move the cursor to the On Delay function
setting and press the [Enter] key to confirm. Use the numeric keys to
set the on delay time and press the [Enter] key to confirm.
Press the up/down key to move the cursor to the Off Delay function
setting and press the [Enter] key to confirm. Use the numeric keys to
set the off delay time and press the [Enter] key to confirm.
4.2.5 Set the Output-On/Output-Off
OVP
Status
Copyright ©ITECH Electronic Co., Ltd.
Power Supply Function
Delay.
Configure over-voltage protection:
41
