Digital IO-4 Settings
Digital IO-5 Settings
Digital IO-6 Settings
Digital IO-7 Settings

set to 'Off
Status'.)
Function setting of pin 4.
On/Off, Select Invert or not under the IO
Reverse Settings. If setting to ON, it means the valid
signal is reversed.


Function



Channel

(Displayed only

when Function is
set to 'Trigger'.)
Function setting of pin 5.
On/Off, Select Invert or not under the IO
Reverse Settings. If setting to ON, it means the valid
signal is reversed.


Function



Channel

(Displayed only

when Function is
set to 'Inhibit'.)
Function setting of pin 6.
On/Off, Select Invert or not under the IO
Reverse Settings. If setting to ON, it means the valid
signal is reversed.

Function


Function setting of pin 7.
On/Off, Select Invert or not under the IO
Reverse
Settings. If setting to ON, it means the valid
Copyright ©ITECH Electronic Co., Ltd.
System-Related Functions
CH1&CH2: Apply the configuration to Ch1
and Ch2.
Trigger Out: Configure IO-4 as Trigger Out
and enable the triggering output (Trig out)
of the List. When the List is triggered to
run, IO-4 will output a pulse signal.
Trigger In: Configure the trigger source of
the Oscilloscope function, Data recording,
and List function to be external. When the
instrument receives an external pulse
signal, it will trigger the running of the
Oscilloscope function, Data Recording
function or List function.
Input: Pin 4 receives the level signal from
the outside.
Output: Pin 4 sends the digital signal (1, 0)
to the outside.
CH1: Apply the configuration to Ch1.
CH2: Apply the configuration to Ch2.
CH1&CH2: Apply the configuration to Ch1
and Ch2.
Inhibit-Living: The power supply will be
operated in the mode of Living.
Inhibit-Latch: The power supply will be
operated in the mode of Latch.
Input: Pin 5 receives the level signal from
the outside.
Output: Pin 5 sends the digital signal (1, 0)
to the outside.
CH1: Apply the configuration to Ch1.
CH2: Apply the configuration to Ch2.
CH1&CH2: Apply the configuration to Ch1
and Ch2.
Sync On: This default function means that
pin 6 performs bi-directional and
synchronous control over the turn-on of
[On/Off].
Input: Pin 6 receives the level signal from
the outside.
Output: Pin 6 sends the digital signal (1, 0)
to the outside.
155
