ITech IT6600C Series User Manual page 13

Model Dual-channel
output
specifications
1200V/±400A/±168kW*2ch
IT66336CM-2250-800
1200V/±450A/±189kW*2ch
IT66378CM-2250-900
Optional accessories
The following optional accessories from ITECH are sold separately. Users need
to purchase separately.
Device Name
GPIB communication
interface
RS232+Analog
EtherCAT
Fiber optic modules and
cables
Fiber optic modules and
cables
Relay board
Series and parallel boxes
1.3 Front Panel

One master and multi-slaves series
All of this series instruments have the same front panel. The front panel
diagram and key diagram of 3U model is shown in the figure below;
descriptions of the numbered items follow the figure.
Parallel output
specifications
1200V/±800A/±336kW*1ch
1200V/±900A/±378kW*1ch
Model Description
IT-E176 When the user needs to use GPIB interface to
enable remote operation, this option is the right
choice.
IT-E177 Interface
communication interface and external analog.
When the user needs to use RS-232 or
external analog interface to enable remote
operation, this option is the right choice.
IT-E1601-black -
IT-E168 Used for parallel connection between the units
in a cabinet, including one fiber module and
two fiber cables, with lengths of 1.5 meters and
0.3 meters.
The fiber optic module and cable are the
necessary
connection. Different numbers of fiber optic
modules and cables are used in different
numbers of parallels.
IT-E169 Used for parallel connection between cabinets,
including one fiber module and one 2.5m fiber
cable.
The fiber optic module and cable are the
necessary
connection. Different numbers of fiber optic
modules and cables are used in different
numbers of parallels.
IT-E179 -
IT-E183 Cabinet
between series and parallel.
Copyright ©ITECH Electronic Co., Ltd.
Series Output
Specifications
2250V/±400A/±336kW*1ch
2250V/±450A/±378kW*1ch
card that includes
accessories for the
accessories for the
configuration, direct
Quick Reference
Height
37U
37U
RS-232
parallel
parallel
switching
4
