ITech IT6600C Series User Manual page 51

Over Current Protection
Over Power Protection
Under Voltage Protection
Under Current Protection
Maximum Voltage Limit
Maximum Current Limit
Maximum Power Limit
4.3.1 Over Voltage Protection
Over-voltage protection function allows the user to enable the protection and set
a over-voltage limit (Level) and delay time (Delay). The function is mainly used
to protect the DUT connected during test to prevent it from damage due to over-
voltage.
How to Set
1. Press [Shift]+[Recall] (Protect) keys and enter to Protection menu.
2. Press the up/down key or rotate the knob to select Over Voltage Protection.
3. Set the protection status, protection Level and the delay time in sequence,
and press [Enter] to confirm.
Clear OVP Protection
When OVP protection occurs, the instrument responds as follows:

Instrument output is off.

The instrument emits an alarm sound every 3 seconds.
Level
Delay
OCP
Status
Level
Delay
OPP
Status
Level
Delay
UVP
Status
Warm up
time
Level
Delay
UCP
Status
Warm up
time
Level
Delay
Sets the maximum voltage value.
Level
Sets the maximum current value.
Output
Sink
Sets the maximum power value.
Output
Sink
Copyright ©ITECH Electronic Co., Ltd.
Power Supply Function
On or Off.
OVP limit.
Protection delay time.
Configure over-current protection:
On or Off.
OCP limit.
Protection delay time.
Configure over-power protection: On
or Off.
OPP limit.
Protection delay time.
Configure under-voltage protection:
On or Off.
Indicates the instrument warm-up
time.
UVP limit.
Protection delay time.
Configure under-current protection:
On or Off.
Indicates the instrument warm-up
time.
UCP limit.
Protection delay time.
The maximum voltage value.
The maximum output current value.
The maximum input current value.
The maximum output power value.
The maximum input power value.
