This chapter briefly introduces the front panel, rear panel, keyboard and screen
display of the product, which provides you with a quick overview of its
appearance, structure and key functions before operating. This chapter will not
specify each operation in detail, it is just a guide to get you started quickly.
1.1 Brief Introduction
IT6600C series DC power supply is a new generation graphical bidirectional DC
power supply. It adopts a touch screen design and intuitive GUI, making
parameter setting and waveform editing simpler and more efficient. It adopts
advanced third-generation SiC technology. A 3U height single unit can output
21kW each in dual channels. If the two independent channels are connected in
series/parallel, it can reach maximum power 42kW. Since 1 unit IT6600C can
cover the output range of 3-5 normal power supplies, it can be applied to various
applications requiring high voltage or high current.
IT6600C series is not only a power supply, but also an excellent electronic load.
It can not only output power as a DC power supply, but also act as a DC
electronic load, absorbing power and feeding clean power back to the grid to
realize energy recycling. IT6600C series brings you a new experience during
the high-power complex testing in the fields of automobiles, energy storage,
industry, green energy and so on and provides strong support for R&D,
verification, production, etc.
Features

Bidirectional, integrating power supply and e-load in one

High power density, up to 42kW in 3U

Independent dual-channel design in 3U unit, and channels can be
connected in series or parallel

High efficient power regeneration

Master-slave current sharing, output max. 10MW in parallel, no
performance lost

5-inch touch screen with intuitive GUI
Dynamic response ≤200us

Rise time ≤1ms

High precision ≤0.03%+30mA


Built-in communication interface: USB/LAN/CAN 2.0B/Digital IO.

Optional communication interface: GPIB/EtherCAT/Analog&RS232.

Built-in standard multi-channel solar array simulation software.

List function, dynamic working condition simulation with tens of millions of
points.

Built-in IEC 61000-4-17/IEC 61000-4-29 waveforms.

Built-in 9 standard automotive voltage curves, including LV123, LV148,
ISO21498-2, etc.
*1. IT6600C can partially meet test requirements of IEC61000-4-17.
