Pins
10 pin Channel 3 The setting for the voltage/current lower limit
Enable/disable analog control
The user needs to select the corresponding function settings in the System
menu. The detailed parameter description is as below.
External Program
Displayed when
CV is prioritized.
Displayed when
CC is prioritized
1. Press the composite keys [Shift] + [P-set] (System) on the front panel to
enter the system menu.
2. Press the up/down key or rotate the knob to find Source->External
program menu.
i.
ii.
3. Press [Esc] to exit.
Analog Conversion Relationship Introduction
The external analog has three channels, and the parameter configuration for
each channel follows a linear function y=kx+b. The parameter explanations are
as follows:

Independent variable x: The actual input voltage value of the external
analog channel.

Slew factor k: Same as Mx in the menu, set by the user.

Offset b: Same as Mb in the menu, set by the user.

y: The actual output value of the instrument. (Voltage when CV is prioritized,
current when CC is prioritized)
Name Description
corresponds to Volt Low/Curr Limit- in the menu.

CV priority: Specify the value of the current lower
limit I-.

CC priority: Specify the value of the voltage lower
limit Vl.
External analog function.(External analog interface is optional.)
Status
Channel
Volt Set Mx
Volt Set Mb
Curr Limit+ Mx
Curr Limit+ Mb
Curr Limit- Mx
Curr Limit- Mb
Curr Set Mx
Curr Set Mb
Volt High Set Mx
Volt High Set Mb
Volt Low Set Mx
Volt Low Set Mb
Set the Set Mx, Set Mb, Limit+ Mx, Limit+ Mb, Limit- Mx and Limit- Mb
in sequence, and press [Enter] to confirm.
Press the up/down key to move the cursor to the Status function setting
and press the [Enter] key to confirm. Rotate the knob to select On to
turn on the external analog function.
Copyright ©ITECH Electronic Co., Ltd.
Set the On/Off state.
Select the analog control channel.
Indicates the slew factor of Volt Set.
Indicates the offset of Volt Set.
Indicates the slew factor of Curr Limit+.
Indicates the offset of Curr Limit+.
Indicates the slew factor of Curr Limit-.
Indicates the offset of Curr Limit-.
Indicates the slew factor of Curr Set.
Indicates the offset of Curr Set.
Indicates the slew factor of Volt Limit+.
Indicates the offset of Volt Limit+.
Indicates the slew factor of Volt Limit-.
Indicates the offset of Volt Limit-.
