displayed as "Trig" when triggered.
Ready Select the trigger mode as "Normal," with the trigger status
displayed as "Ready" when not triggered.
Stop When the "Stop" key in the waveform display interface is
pressed, the trigger status Stop will be displayed.
Description of keys on the waveform display interface:

AutoSet: Automatically adjust the appropriate time base, voltage/current
scale, and restore the trigger level and trigger delay to default values.

Voltage/Current/Time: Adjust voltage/current/time base range.

Single: Single measurement key: when single measurement is enabled in
the Stop status, the stop status is enabled again after one measurement
based on the current data updating rate. When single measurement is
enabled in the Ready status, the instrument immediately restarts one
measurement and then enters the Stop status.

Run/Stop: press the corresponding soft key to run or stop the waveform
status.

More: Advanced configuration options for oscilloscope function.
Parameter
Trigger source
Trigger mode
Print data
Copyright ©ITECH Electronic Co., Ltd.
Description
Select trigger source, Voltage, Current and External
can be select.

Voltage trigger. When the DC terminals detect that
the voltage reaches the trigger voltage setting
value and is within the range of the upper and
lower trigger limits, a data recording operation is
triggered.

Trig Level: Trigger threshold.

Edge: Select trigger edge: rising edge (Rise),
descending edge (Fall) or either edge (Both).

Trig High: Trigger upper limit value.

Trig Low: Trigger lower limit value.

Current trigger. When the DC terminals detect that
the current reaches the trigger current setting
value and is within the range of the upper and
lower trigger limits, a data recording operation is
triggered.

Trig Level: Trigger threshold.

Edge: Select trigger edge: rising edge (Rise),
descending edge (Fall) or either edge (Both).

Trig High: Trigger upper limit value.

Trig Low: Trigger lower limit value.

External: Indicates the trigger occurs via the pin 4
of the digital I/O interface (P-IO). For details, see
5.9 Digital I/O Function.
Auto and Normal can be select.
Save the data.
 Depth: data record depth.
 Algorithm: with the option of Normal or Peak.
Measurement Functions
