Please pay attention to whether the voltage value defined in the LV123
standard matches the rated voltage of the instrument, otherwise some
waveforms cannot be recalled.
LV123 waveform protocol
Mode Select the LV123 waveform editing method Curve or Userdefined.
Curve
Userdefined
Copyright ©ITECH Electronic Co., Ltd.
Choose to recall the standard LV123 waveform.
Limit Range
Unlimited
Upperlimited Range of upper limited
Lowerlimited Range of lower limited
Highlylimited Range of highly limited
Start voltage Set the initial output voltage of the
instrument before the LV123 regulation
waveform test. At the same time, this
value is also the end voltage after the
regulatory waveform test is completed.
Start time Test time of starting voltage, range:
0~999.999S.
End time Test time of end voltage, range:
0~999.999S.
Count Set the number of test repetitions,
ranging from 1 to 65535.
Select the user-defined LV123 waveform.
Voltage Range
Unlimited
Power Supply Function
Range of unlimited
operating capability,
includes the following
options:

HV_1

HV_2a

HV_2b

HV_3
operating capability,
includes the following
options:

HV_1

HV_2a

HV_2b

HV_3
operating capability,
includes the following
options:

HV_1

HV_2a

HV_2b

HV_3
operating capability,
includes the following
options:

HV_1

HV_2a

HV_2b
Range of unlimited
operating capability,
