Keys
[Shift]+[Recall](Protect)
[Shift]+[1](Log)
[Shift]+ [2] (Lock)
[Shift]+[3] (Local)
[Shift]+[4] (Save)
[Shift]+ [5] (Trigger)
[Shift]+ [6] (Hold)
[Shift]+ [7] (Help)
Push-on Knob
The IT6600 series Power Supply provides a knob on the front panel as shown
in the next figure.
The functions of the posh-on knob is described as follows.

Adjust the value setting.

Select menu item.

Confirm the set value or the selected menu item.
Adjust the Value Setting
In the value setting interface, rotate the knob clockwise to increase the set value
and anticlockwise to decrease the set value.
Select Menu Item
The knob can also be used to view menu items. In the menu item display
interface, turning the knob clockwise indicates that the next menu item is
selected, and turning the knob anticlockwise indicates that the previous menu
item is selected.
Confirm settings
After completing the value setting or selecting a menu item, pushing the knob
acts like pressing [Enter] key to confirm the operation.
1.5 Rear Panel

One master and multi-slaves series
The rear panel of the IT6600 series 3U model is shown below.
Description
Enter the Protect menu of the power
supply.
Enter the Log query interface.
Turn the keyboard lock on or off.
Switch remote control mode to local
control mode.
Save the common parameter settings.
Used for manual trigger.
When you need to keep the present meter
status, you can press the keys. Then the
present meter status display and will be
kept no matter whether output is running.
Obtain the help information.
