Configure LAN Interface Information
The configurable parameters of the IT6600 series power supply are described as
follows.
LAN Config：





How to Configure
Take manual configuration as an example. The steps are as follows:
1.
2.
3.
4.
8.2.1 Using Web Server
The instrument has a built-in Web server for monitoring and controlling the in-
strument via a Web browser in PC. To use the Web server, connect the instru-
ment and PC over LAN interface and enter the instrument's IP address into the
address bar at the top of your PC's Web browser, you can access the front panel
control functions including the LAN configuration parameters.
services such as DHCP and DNS servers. When connected to a computer,
a network cable can be used to connect to the router, and the computer
is also con- nected to the router.
When using one crossover cable to connect PC directly, the gateway
address of the instrument should be consistent with that of the PC, and
the IP address should be at the same network segment with the PC's IP
address.
When the instrument and computer are connected to the router, an
independent IP address must be assigned for the instrument.
Mode: IP Address seting method, user can selectautomatically configure the
address of the instrument(DHCP) or manually.
IP: This value is the Internet Protocol (IP) address of the instrument. An IP
address is required for all IP and TCP/IP communications with the instru-
ment. An IP Address consists of 4 decimal numbers separated by periods.
Each decimal number ranges from 0 through 255 with no leading zeros (for
example, 169.254.2.20).
Mask: This value is used to enable the instrument to determine if a client IP
address is on the same local subnet. The same numbering notation applies
as for the IP Address. When a client IP address is on a different subnet, all
packets must be sent to the Default Gateway.
Gateway: This value is the IP Address of the default gateway that allows the
instrument to communicate with systems that are not on the local subnet, as
determined by the subnet mask setting. The same numbering notation ap-
plies as for the IP Address.
Socket Port: This value indicates the port number corresponding to the
service.
Press the composite keys [Shift] + [P-set] (System) on the front panel to
enter the system menu.
Select Communication and press [Enter].
Press the Left/Right key to select LAN and set the mode to Manual.
Set the IP, Mask and the other parameters in turns, and press [Enter].
