Cooling
NET Dimension ( mm)
Weight( net)
*1. This specification was tested under test conditions with an output voltage of ≥30V.
*2. When input with 198 to 264Vac three phase input, max. power derated to 50% of the rated
power at 40°C and to 40% of the rated power output at 50°C.
*3. Multi-master cabinet, that is, optional emergency stop module (including AC contactor) models,
the standard AC input voltage only supports 380VAC ± 10%, such as the need for 480VAC ± 10%
voltage need to be customized.
*4. Power factor of 0.99 at 50% of rated power and above at nominal input.
7.2.3 2250V
Rated value
Line Regulation
Load Regulation
Setup Resolution
Read Back
Resolution
Setup Accuracy
Read Back Accuracy
Ripple *1
Parameter
Voltage
mode/Parallel mode
Current
mode/Series mode
Power
Resistance in
series (CV priority)
Load resistance
(CC priority)
Voltage
Current
Voltage
Current
Voltage
Current
Power
Resistance
Voltage
Current
Power
Voltage
Current
Power
Voltage
Current
Power
Vpp
Copyright ©ITECH Electronic Co., Ltd.
435mm(W)* 132mm(H)*700mm(D)
(Depth 790mm including protective cover)
Series mode
2-channel
Parallel mode
2-channel
Each channel
Total
2-channel mode
Parallel mode
Series mode
2-channel mode
Parallel mode
Series mode
≤0.005%FS
≤0.005%FS
≤0.005%FS
≤0.01%FS
0.001V
0.001A
0.001kW
0.001Ω
0.001V
0.001A
0.001kW
≤0.02%+0.01%FS
≤0.03% + 0.03%FS
≤0.05% + 0.1%FS
≤0.02%+0.01%FS
≤0.03% + 0.03%FS
≤0.05% + 0.1%FS
20Hz-20MHz
Technical Specifications
Air
48.5kg
IT6642C-2250-100
0～2250V
0～1200V
-100A～100A
-50A～50A
-21kW～21kW
-42kW～42kW
0～2.4Ω
0～1.2Ω
0～4.5Ω
0.092～7500Ω
0.046～7500Ω
0.183～7500Ω
≤0.1%FS
