ITech IT6600C Series User Manual page 143

RS232 Settings
GPIB Settings
CAN Settings
IO menu
Digital IO-1 Settings
Digital IO-2 Settings
Digital IO-3 Settings
IO
Digital IO-4 Settings
Digital IO-5 Settings
Digital IO-6 Settings
Digital IO-7 Settings
Product model
SN
Software version
MAC address
Rbf version
Ctrl1 version
Information
Ctrl2 version
Inner numbers
Power On Time
Current Output Time
History Output Time
Mode
IP
Mask
Gateway
Port
Select RS-232 communication interface. When insert
IT-E177 communication board into expansion slot, the
menu displays this information.
Baud rate
Data bits
Stop bits
Even-odd check
Address
Select GPIB communication interface. When insert IT-
E176 communication board into expansion slot, the
menu displays this information.
Address
CAN communication interface.
Baud rate
Address
Protocol
Set Digital I/O. For detailed introduction of menus and
functions, see 5.9 Digital I/O
Display the instrument model.
Display the serial number.
Display the system version information.
MAC address
Rbf version
Ctrl1 version
Ctrl2 version
Number of inner ring parallel instruments.
The power on time of the instrument.
The current output time of the instrument.
The history output time of the instrument.
Copyright ©ITECH Electronic Co., Ltd.
System-Related Functions

DHCP: automatically configure
the address of the instrument.

Manual: manually configure
the address of the instrument
by entering values in the
following five fields.
Set the IP address.
Set the subnet mask.
Set the gateway address.
Set the port number.
Baud rate
Data bit: 5/6/7/8
Stop bit: 1/2
Parity bit: N (No parity) / E (Even
parity) / O
(Odd parity)
Address
Set the communication address
Select the baud rate
Set the instrument address to a
number

CAN_OPEN: High-level
protocol for the CAN bus.

CAN2.0: ITECH CAN version
2.0 protocol.
Function.
