Chapter5 System-Related Functions
5.1 System Menu Reference
Press [Shift] + [P-set] (System) to enter the menu function. At this time, LCD
displays optional menus. Select and edit the menu items by pressing the Up,
Down, Left and Right keys. Specific menu items are shown below. The menu
items are shown below.
Source menu
Output Mode
Source
Remote sense
Output Rzero
External Program
Measure
Power Unit
Setting
Set the output mode.



Mode

Sync

Sync Mode Synchronization mode.
Track: Set 2-channel to output on/off
synchronization and voltage proportional
changing.

Onoff Only: Set 2-channel to output on/off
synchronization.
Duplicate：Set the parameters of 2-
channel to be fully synchronized.
Set the sense function state.

Status

Used to control whether the voltage is quickly zeroed after the
output is turned off.

Status

External analog function.(External analog interface is optional.)
For detailed introduction of menus and functions, see
Analogue Function.
Set the measurement speed.
Low Low mode, measuring every 200ms.
Medium Medium mode, measuring every 100ms.
Fast Fast mode, measuring every 20ms.
Set the power unit: W or kW.
Copyright ©ITECH Electronic Co., Ltd.
System-Related Functions
Series: Configure the instrument to 2-
channel series mode.
Parallel: Configure the instrument to 2-
channel parallel mode.
Dual: Configure the instrument to 2-
channel independent output mode.
When the output mode of the
instrument is configured Dual, the
synchronization parameters of both
channels can be further configured.
On: Turns on the 2-channel
synchronization mode.
Off: Turns off synchronization mode.
Reference: Set the voltage proportional
relationship among 2-channel.
On: Enable the remote sense
Measurement.
Off: Disable the sense function.
On：Yes
Off：No
