ITech IT6600C Series User Manual page 183

Cooling
NET Dimension ( mm)
Weight( net)
*1. This specification was tested under test conditions with an output voltage of ≥30V.
*2. When input with 198 to 264Vac three phase input, max. power derated to 50% of the rated
power at 40°C and to 40% of the rated power output at 50°C.
*3. Multi-master cabinet, that is, optional emergency stop module (including AC contactor) models,
the standard AC input voltage only supports 380VAC ± 10%, such as the need for 480VAC ± 10%
voltage need to be customized.
*4. Power factor of 0.99 at 50% of rated power and above at nominal input.
7.2.2 1600V
Rated value
Line Regulation
Load Regulation
Setup Resolution
Read Back Resolution
Setup Accuracy
Read Back Accuracy
Parameter
Voltage
Current
mode/Series mode
Power
2-channel mode
Resistance in
series (CV priority)
2-channel mode
Load resistance
(CC priority)
Voltage
Current
Voltage
Current
Voltage
Current
Power
Resistance
Voltage
Current
Power
Voltage
Current
Power
Voltage
Current
Power
Copyright ©ITECH Electronic Co., Ltd.
Air
435mm(W)* 132mm(H)*700mm(D)
(Depth 790mm including protective cover)
48.5kg
Series mode
2-channel
mode/Parallel
mode
Parallel mode
2-channel
Each channel
Total
Parallel mode
Series mode
Parallel mode
Series mode
≤0.005%FS
≤0.005%FS
≤0.005%FS
≤0.01%FS
0.001V
0.001A
0.001kW
0.001Ω
0.001V
0.001A
0.001kW
≤0.02%+0.01%FS
≤0.05% + 0.03%FS
≤0.03% + 0.1%FS
≤0.02%+0.01%FS
≤0.03% + 0.03%FS
≤0.05% + 0.1%FS
Technical Specifications
IT6642C-1600-120
0～1600V
0～800V
-120A～120A
-60A～60A
-21kW～21kW
-42kW～42kW
0～1.334Ω
0～0.667Ω
0～2.667Ω
0.102～7500Ω
0.051～7500Ω
0.204～7500Ω
174
