3.
4.
5.
Select/Run Bat-SIM File
1. Click BMS on the Menu screen to enter the Bat-SIM function main interface.
2. Press [Open], select the saved Bat-SIM01 csv file, and press [Enter] to
enter the file.
3. Set Init Soc, Init Cap, Init Voc (only required for Userdefined mode), and
press the [Update] button.
4. Press [On/Off] on the front panel, turn on the output.
5. Press [Run] in the Bat-SIM function interface.
6. Press [Shift]+[5](Trigger) on the front panel to run the Bat-SIM test.
7. Click [Stop] to stop the present running.
Parameter Description

Running Init Soc: Set the initial state of charge (Soc) of
Settings the battery. 0~100% corresponds to the voltage
range from no-load voltage to full-load voltage.

Init Cap: Set the initial battery capacity.

End Mode: Set the running state after the Bat-
SIM execution is finished.
Last: Maintains the final voltage output after the
end of charge or discharge.
Normal: The device shuts down output and
returns to normal.
Last+Off: After the charge and discharge
process is completed, retain the final parameter
settings and turn off the output.
Fill in corresponding parameter in the Bat-SIM edit interface. Click
[More] enter to advanced menu of Bat-SIM file.
Press [Esc] to return Edit interface, Press [Save].
Press [Esc] to return and the interface appears with the edited Bat-SIM
file.
