Import via U disk
The instrument supports importing the edited .csv format file (the template can
be obtained by contacting ITECH personnel) through the USB interface on the
front panel, and generating voltage or current values after parsing, and then
outputting complex voltage or current waveforms according to the time width
specified by the user. The user can edit a .csv file containing up to 80 million
voltage or current points and import it into the instrument for running to realize
arbitrary waveform output or working condition simulation.
The instrument has the ability to quickly parse data. A .csv file of dozens of
megabytes can be imported and parsed within 5S, making testing more
convenient and efficient.
This instrument supports importing the .csv files corresponding to the following
waveforms:

CDWELL: Constant dwell arbitrary waveform
The fields included in the .csv template file are explained as follows:

List: User-defined waveform
The fields included in the .csv template file are explained as follows:
Model Device model, keep the default settings without
modification.
Firmware Version Firmware version number, keep the default settings
without modification.
Serial Number Device serial number, keep the default settings
without modification.
File Type File type, keep the default settings without
modification.
Waveform Type Waveform type, keep the default settings without
modification.
Value Unit The CV priority is set to V, and the CC priority is set
to A.
Offset Unit Offset value unit, CV priority is set to V, CC priority
is set to A.
Time Unit Time unit, fixed to S.
Mode Indicates the power supply working mode. The CV
priority is set to CV, and the CC priority is set to CC.
Repeat Repeat times, the setting range is 1~65535.
End State Indicates the end state. Last (voltage or current
maintained at the last point after completion) or
Normal (return to the mode before CDWELL
execution after completion).
Total Point The total number of waveform points.
Keep Time Indicates the pulse width of each point. Range:
0~3600. Unit: seconds.
Value Voltage or current value at each point.
Model Device model, keep the default settings without
modification.
Firmware Version Firmware version number, keep the default settings
without modification.
Serial Number Device serial number, keep the default settings
without modification.
File Type File type, keep the default settings without
modification.
Waveform Type Waveform type, keep the default settings without
