Table E-3 (Cont.) Cooling Unit Components
Component Name IPMI Type
(Oracle ILOM CLI
Targets)
/SYS/MB/FM[0-5] / Discrete
PRSNT sensor
/SYS/MB/FM[0-5] /F[0- Threshold
x]/TACH sensor
/SYS/MB/FM[0-5] / Indicator
SERVICE

Disk Backplane Components

The following table lists the disk backplane (DBP) components.
Table E-4

Disk Backplane Components

Component Name IPMI Type
(Oracle ILOM CLI
Targets)
/SYS/DBP FRU
/SYS/DBP/PRSNT Discrete
sensor
/SYS/DBP/HDD[0- x ] FRU
Discrete
/SYS/DBP/HDD[0- x ]/
PRSNT sensor
/SYS/DBP/HDD[0- x ]/ State
sensor
STATE
Indicator
/SYS/DBP/HDD[0- x ]/
SERVICE
/SYS/DBP/HDD[0- x ]/ Indicator
OK2RM
FRU
/SYS/DBP/HDD[0- x ]/
NVME
Description
Fan module is present.
Fan module fan speed
Fan Fault-Service Required LED
Description
Disk backplane FRU
Disk backplane presence (Hidden)
Hard disk drives (HDD)
Hard disk drive presence(Hidden)
Hard disk drive state
Fault-Service Required LED
Hard disk drive OK to remove
NVMe drive FRU
Appendix E
Disk Backplane Components
Values (if applicable)
01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
RPM
Color: Amber
Location: Motherboard
Off: Normal
On: Fan module was
diagnosed as faulty.
Values (if applicable)
01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
01h-FAULT_STATUS
02h-IDENTITY
04h-INSTALLED
20h-SLOT_POWER_OFF
Color: Amber
Location: HDD
Off: Normal
On: HDD was diagnosed as
failed
Color: Blue
Location: HDD
Off: Normal
On: HDD is OK to remove
E-4
