Control Module

1.16.1.3.5 TPTC Configuration Register (TPTC_CFG)

The TPTC_CFG register configures the default burst size for TPTC0, 1, 2, and 3.
The TPTC Configuration Register (TPTC_CFG) is shown in
31
7 6
TC3DBS
R/W-11
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 1-202. TPTC Configuration Register (TPTC_CFG) Field Descriptions
Bit Field
31-8 Reserved
7-6 TC3DBS
5-4 TC2DBS
3-2 TC1DBS
1-0 TC0DBS
304
Chip Level Resources
Preliminary
Figure 1-161. TPTC Configuration Register (TPTC_CFG)
Reserved
R-0
5 4
TC2DBS
R/W-11
Value Description
0 Reserved. Read returns 0.
TC3 Default Burst Size
0 16 byte
01 32 byte
10 64 byte
11 128 byte
0-3h TC2 Default Burst Size.
0-3h TC1 Default Burst Size.
0-3h TC0 Default Burst Size.
© 2011, Texas Instruments Incorporated
Figure 1-161 and described in
3 2
TC1DBS
R/W-11
Submit Documentation Feedback
www.ti.com
Table 1-202.
8
1 0
TC0DBS
R/W-11
