1.15.5.7 ELM Page Definition Register (ELM_PAGE_CTRL)

The ELM Page Definition Register (ELM_PAGE_CTRL) is shown in
Table 1-141.
31
7 6
SECTOR_7 SECTOR_6
R/W-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 1-141. ELM Page Definition Register (ELM_PAGE_CTRL) Field Descriptions
Bit Field
31-8 Reserved
7 SECTOR_7
6 SECTOR_6
5 SECTOR_5
4 SECTOR_4
3 SECTOR_3
2 SECTOR_2
1 SECTOR_1
0 SECTOR_0
SPRUGX9 – 15 April 2011
Submit Documentation Feedback
Preliminary
Figure 1-103. ELM Page Definition Register (ELM_PAGE_CTRL)
5 4
SECTOR_5 SECTOR_4
R/W-0 R/W-0
Value Description
0 Reserved.
0-1 Set to 1 if syndrome polynomial 7 is part of the page in page mode. Must be 0 in continuous
mode.
0-1 Set to 1 if syndrome polynomial 6 is part of the page in page mode. Must be 0 in continuous
mode.
0-1 Set to 1 if syndrome polynomial 5 is part of the page in page mode. Must be 0 in continuous
mode.
0-1 Set to 1 if syndrome polynomial 4 is part of the page in page mode. Must be 0 in continuous
mode.
0-1 Set to 1 if syndrome polynomial 3 is part of the page in page mode. Must be 0 in continuous
mode.
0-1 Set to 1 if syndrome polynomial 2 is part of the page in page mode. Must be 0 in continuous
mode.
0-1 Set to 1 if syndrome polynomial 1 is part of the page in page mode. Must be 0 in continuous
mode.
0-1 Set to 1 if syndrome polynomial 0 is part of the page in page mode. Must be 0 in continuous
mode.
