VLT Micro Drive FC 51

4.13. Parameter Group 16: Data Readouts

4.13.1. 16-** Data Readouts
Parameter group for data read-outs, e.g. actual references, voltages, control, alarm, warning and
status words.

4.13.2. 16-0* General Status

Parameters for reading the general status, e.g. the calculated reference, the active control word,
status.
16-00 Control Word
Range:
*
0
16-01 Reference [Unit]
Range:
0.000
16-02 Reference %
Range:
*
0.0
16-03 Status Word
Range:
*
0
16-05 Main Actual Value %
Range:
*
0.00

4.13.3. 16-1* Motor Status

Parameters for reading the motor status values.
16-10 Power [kW]
Range:
0 kW
Function:
[0 - 65535] View latest valid control word sent to frequency converter via
serial communication port.
Function:
* [-4999.000 - View total remote reference. Total reference is sum of pulse,
4999.000] analog, preset, LCP potmeter, local bus and freeze reference.
Function:
[-200.0 - 200.0%] View total remote reference in percent. Total reference is sum
of pulse, analog, preset, LCP potmeter, local bus and freeze
reference.
Function:
[0 - 65535] View status word sent to frequency converter via serial com-
munication port.
Function:
[-100.00 - 100.00%] View two-byte word sent with status word to bus Master re-
porting main actual value.
Function:
* [0 - 99 kW] View output power in kW.
