Parameter Descriptions

4.13 Parameter Group 16: Data Readouts

16-00 Control Word
Range:
0 [0-65535] View latest valid control word sent to frequency
*
16-01 Reference [Unit]
4 4
Range:
0.000 [-4999.000-4999.000] View total remote reference. Total
*
16-02 Reference %
Range:
0.0 [-200.0-200.0%] View total remote reference in percent.
*
16-03 Status Word
Range:
0 [0-65535] View status word sent to frequency converter via
*
16-05 Main Actual Value %
Range:
0.00 [-100.00-100.00%] View two-byte word sent with status
*
16-09 Custom Readout
Range:
0.00 [0.00-9999.00%]
*
4.13.1 16-1* Motor Status
16-10 Power [kW]
Range:
0 kW [0-99 kW]
*
16-11 Power [hp]
Range:
0 hp [0-99 hp ]
16-12 Motor Voltage
Range:
0.0 [0.0-999.9 V]
*
48
VLT
Function:
converter via serial communication port.
Function:
reference is sum of pulse, analog,
preset, LCP potentiometer, local
bus and freeze reference.
Function:
Total reference is sum of pulse, analog,
preset, LCP potentiometer, local bus and
freeze reference.
Function:
serial communication port.
Function:
word to bus Master reporting main
actual value.
Function:
Customized readout based on the
settings of 0-31 Custom Readout Min
Scale, 0-32 Custom Readout Max Scale
and 4-14 Motor Speed High Limit
Function:
View output power in kW.
Function:
View output power in hp.
Function:
View motor phase voltage.
MG02C602 - VLT
®
Micro Drive FC 51 Programming Guide
16-13 Frequency
Range:
0.0 Hz
*
16-14 Motor Current
Range:
0.00 A
*
16-15 Frequency [%]
Range:
0.00 [-100.00-100.00%] View a two-byte word reporting actual
*
16-18 Motor Thermal
Range:
0% [0-100%] View calculated thermal motor load as
*
4.13.2 16-3* Drive Status
16-30 DC Link Voltage
Range:
0 V [0-10000 V]
*
16-34 Heat Sink Temp.
Range:
0 [0-255°C] View heat sink temperature of frequency
*
16-35 Inverter Thermal
Range:
0% [0-100%] View calculated thermal load on frequency
*
16-36 Inv. Nom. Current
Range:
0.00 A [0.01-655A] View continuous nominal inverter current.
*
16-37 Inv. Max. Current
Range:
0.00 A [0.1-655A] View intermittent maximum inverter current
*
16-38 SL Controller State
Range:
0 [0-255]
*
4.13.3 16-5* Ref. & Feedb.
16-50 External Reference
Range:
0.0% [-200.0-200.0%] View sum of all external references in
*
®
is a registered Danfoss trademark
Function:
[0.0-400.0 Hz] View output frequency in Hz.
Function:
[0.00-655 A] View motor phase current.
Function:
motor frequency as a percentage of
4-14 Motor Speed High Limit
Function:
percentage of estimated thermal motor load.
Function:
View DC-link voltage.
Function:
converter.
Function:
converter in relation to estimated thermal load
on frequency converter.
Function:
Function:
(150%).
Function:
View number of active SLC state.
Function:
percent.
