To configure security to be activated by a digital input press Security via Digital Input
Enable security via DIN by pressing the Toggle button
•
Select a digital input tag. By default, this is set to DIN 20 on the top board. Any digital tag in the
•
system can be selected, allowing greater flexibility then just using Digital Inputs. To choose
another Digital Input, simply use the tag browser to find the appropriate DIN, and choose
ValueDigital (see Figure 84 and Figure 85 in Section 11.1 below).
Press Save
•
Figure 83 – Configure Security via DIN

11.1 Selecting any Digital Input Tag

The screens below show how to navigate to any digital input tag.
Find the IO Module in Advanced and using the
Input you are looking for.
Please Select: Digital Tag
Name
_I O
....CAN Baud Rate
....Demo Case
....Unit
..._1
...Bottom Board
...DcVolt s
...Probe
...System
...Top Board
...+
Clear
Figure 84 – Tag browser screen
Page 74 of 201
MultiSmart Installation & Operation Manual
Type
Node
Node
Attribute In
Attribute B
Node
Node
Node
Node
Node
Node
Ain Node
Cancel
+ / -
button expand out the tree view to get to the Digital
Select
+ / -
OK
