MultiSmart Installation & Operation Manual
9.1.4 RTU Setup
Yes
New settings applied
and unit restarted
Figure 70 – Setup Wizard - 4 of 4

9.2 Setup Wizard Notes

9.2.1 Key Setup Wizard Parameters
While half of the parameters specified during the Setup Wizard can be modified (if necessary) at a later date
through other menus, the remaining key setup parameters can only be changed through the Setup Wizard so
it's important that these parameters are correct the first time.
The Setup Wizard can be run any number of times but each time it clears the memory so any other
configuration changes made are lost and must be re-entered (if still required). The key setup parameters are
listed below.
Table 5 – Key Setup Parameters (can only be modified through the Setup Wizard)
MultiSmart_IO_Manual_A4_v2-22_R15.doc
Select the no. of MultiSmart
units in the Pump Station
Select the type of Board
installed in Unit 1:
3PC/3MP/None
DNP3 address setup
Check setup summary
Yes / No
Return to "select station type" screen
in Setup Wizard diagram
Key Setup Parameter
Station Type
Station Mode
Number of MultiSmart Units
Board in Bottom Slot
Number of Wells
Number of Pumps
No
Options
Pump Station, Reservoir, RTU
Fill, Empty
1-10
3PC, 3MP, None
1-3
1-9
