15.1.2 Selecting Profiles Using a Digital Tag
A digital tag whether for a digital input or for some other source can be assigned to select a profile:
From the tree select: Pump Control
•
Select the desired profile from the list and press
•
From the tree select: DIN Activation
•
Any digital tag (of type "DigitalTag") can be selected. In this example a digital input is the source.
The following values should be set:
Enabled? (check the box to enable, uncheck to disable)
•
Source (contains the digital tag source), press "Use this button to see additional values".
•
Scroll down to IO, press
•
Select the DIN to be use. Scroll down to ValueDigital, and Press Ok.
•
15.1.3 Selecting Profiles Using a Timer
A timer can be used to set a specific date/time for a profile to be selected. Timer settings for each profile are
accessed through the advanced menu:
From the tree select: Pump Control
•
Select the desired profile from the list and press
•
From the tree select: Timers
•
Select the desired timer and press
•
The following values can be set for each timer:
Enabled? (check the box to enable, uncheck to disable)
•
Period (Days) (The repeat period for the timer, 1-28 days)
•
Start date (only the date is actually used on this screen, the time is not used). This start date only
•
needs to be set if the timer is to be activated at some time in the future, or you want the timer to run
on a specific day each week (in which case you would set Period = 7)
Start time (this is the actual start time used by the timer)
•
Stop time
•
