19.6 Summary of Datalogger File Functions

Following is a summary of the function of the Datalogger files saved to the compact flash card. (The name of
the datalogger file changes slightly when saved to the compact flash card).
Fault Log
The fault log records all faults that occur. Around 50 000 records are saved per file after which the file rolls
over to faults.0.
Event Log
The event log records all events that occur within defined dead bands (a minimum amount by which the
value must change before it is logged). Around 50 000 records are saved per file after which the file rolls
over to events.log.0.
EFault Log
Events are logged surrounding a fault. Around 50 000 records are saved per file after which the file rolls
over to faults.log.0. The events logged are timed based (not dead band based as per events.log) i.e. after a
fixed amount of time, the status of the event is logged. A buffer is maintained so that these events are
captured before and after a fault occurs.
Fault Type
Fault Log
Event Log
Efault Log
(Fault-Event Log )
Table 25 – Summary of Data Logged Files
1. A configurable number of previous files (or file generations) can be retained.*
- For the Fault Log:- Settings / Advanced / FaultModule / Number of file generations, by default it is
set to 3.
- For the Event Log & Efault Log:- Settings / Advanced / Event Logger / Number of file generations,
by default it is set to 2.
NOTE: * Show More Options must be enabled.
MultiSmart_IO_Manual_A4_v2-22_R15.doc
Function
Records all faults that
occur.
Records all events that
occur within a defined
dead band.
Records all events before
& after a fault. The events
logged are timed based
(not dead band).
On MultiSmart
Current Previous
File Files
faults.txt faults.txt.0
faults.txt.1
faults.txt.2
(See note 1)
events.log events.log.0
events.log.1
events.log.2
faults.log faults.log.0
faults.log.1
faults.log.2
On CF Card
Current Previous
File Files
faults.txt faults.0
faults.1
faults.2
events.log events.0
events.1
events.2
efaults.log efaults.0
efaults.1
efaults.2
Page 141 of 201
