16.2 Additional Parameters

Pressing the Advanced button on the Optimization screen, displays the advanced settings screen where a
large number of additional pump control settings may be found, including the following settings.
16.2.1 Max. Number Groups Running
This feature is used to control how many groups run at same time. This function is only required when more
than one group has been configured. It can be used to restrict groups from running at the same time, for
example, making sure jockey pumps do not run when flood pumps are running. The feature is on by default
and set to 1.
16.2.2 Group
When more than one group of pumps have been configured (see Section 13.3), different parameters can be
set for each group. For example, Max Pumps Running can be set differently for group 1 and group 2.
16.2.3 Pulse Start & Pulse Stop
A digital input can be assigned to the Pulse Start option through the advanced menu. The example below
shows how to assign Digital Input 12 to Pulse Start:
From the tree select Pump Control
•
Scroll down to Source and press "Use this button to view or change value."
•
From within the Digital tag tree, scroll down to IO
•
Select the board that contains the Digital Input, in this case the Top Board
•
Scroll down to chosen digital input, (DIN.12 shown here) _12
•
Scroll down to a DigitalTag, select ValueDigital, press Ok, then press Save
•
Use the Back button to return to the main screen.
•
To activate the Digital Input a restart is required.
(Alternatively cycle the power).
16.2.4 Assigning a Name to Digital Inputs (Optional)
A descriptive name such as "Pulse Start Input" can be assigned to Digital Input 12 as shown below:
Navigate through the tree:
•
IOModule
Under Description enter a new name.
•
Press Save and return to the main screen using the Back button.
•
The changes to the Digital Input name can be confirmed by going to:
Scroll down to TopBoard Din 12 and the new name should appear in right column.
16.2.5 Well
Parameters can be set for how primary & backup level devices function, and when backup devices take over.
Page 126 of 201
MultiSmart Installation & Operation Manual
(This is the direct path).
+ / - + / -
Unit Unit 01
+ / - + / -
Pulse Start
+ / -
Unit
+ / - + / -
Top Board Digital Input
+ / -
Pulse Start 01
+ / - + / -
_1
+ / -
then Din
+ / -
+ / -
DIN.12
