Primary Level Fault
Backup Level Fault
Table 15 – Digital Output Sources
*Application failure is the internal watchdog functionality.
If the desired source can not be found in this list, press the Advanced button, this displays the Tag Browser
and it allows the selection of any digital tag within the system.
14.11.1 Advanced Digital Output Options
Advanced configuration options for Digital Outputs can be found in the Advanced menu. These options
include inverting, enabling it to flash and delaying the activation or deactivation of the output.
A source (or multiple sources) and the Boolean operator can be assigned in the Digital Outputs screen.
Refer to the previous section for details.
To perform the advanced operations navigate to:
and select a digital output.
Name
Count
Description
Invert?
Mode
(5 modes)
Multiple Sources
Logic
Non Volatile?
Source
Sources 2,3,4
T Closed
T Opened
Table 16 – Advanced Digital Output Options
Page 116 of 201
MultiSmart Installation & Operation Manual
Pump 1 Unavailable
-etc to number of pumps
Description
Sets the number of times to pulse the output but only applies if Mode is set to one
of the pulsing modes.
Description of the output. This is the name displayed in the Info screens.
Turns the Normally Open output into a Normally Closed output.
Normal/Latch
Output is on for the duration the source is active (default).
Flash
Output toggles according to the T Closed & T Opened values.
The activation or deactivation of the output is delayed according
Delay
to the T Closed & T Opened values.
Pulse, Uses the 'Count' variable to pulse the output while T Closed & T
Pos Trigger Opened sets the period.
Pulse, Uses the 'Count' variable to pulse the output while T Closed & T
Neg Trigger Opened sets the period.
Allows a Boolean operation to be performed on the multiple sources.
(The one operator is applied to all sources).
If set to true, the state of the output will be restored after a restart.
The primary source for the digital output.
Up to 3 more sources can be specified.
Number of milliseconds that the relay is to be closed (on) for when flashing or
pulsing.
Number of milliseconds that the relay is to be opened (off) for when flashing or
pulsing.
Any Pumps Off
All Pumps Off
MultiSmart_IO_Manual_A4_v2-22_R15.doc
AIN2 Over Range
AIN2 Under Range
Range/Type
Integer
Text
True/False
And, Or, Xor
True/False
Digital Tag
Digital Tag
Integer
Integer
