16.1.3 Well Clean Out
This feature allows the pumps to be run past the normal deactivation point for a set time or to a set level in
order to completely empty the well. This can be made to occur at regular periods.
Mode
Delay Adjustment (secs)
Level Adjustment (%)
Figure 126 - Well Cleanout Screen
16.1.4 Well Washer
A well washer can be controlled by the MultiSmart in order to coordinate its use with the pumping cycles.
Name
Enabled?
Activation Level
Activation Delay
Max On time
Inter-Start Period
Maximum Off Time
Table 18 – Well Washer Parameters
NOTE: It will also be necessary to configure a digital output to activate the well washer. In particular
you will need to set the digital output source to the well washer "active" tag. See Section 14.11 for a
description of how to configure digital outputs.
Page 124 of 201
MultiSmart Installation & Operation Manual
Disabled
Well Cleanout Help Text
The Mode defines the condition upon which a well cleanout will be activated. The
following modes are available:
• Disabled
• Pump Cycles (activate well cleanout after a defined no. of pump cycles)
• Timers (activate well cleanout when a timer becomes active)
Pump Cycles and Timers (activate well cleanout after a no. of pump cycles or when a
timer become active)
Description
Toggle this value to enable or disable the well-washer feature.
Sets the level at which the washer is activated.
Sets a delay after the Activation Level is reached before the well washer is started.
Maximum run time for the well-washer
Ensures the well washer does not run too often
Sets a maximum time the well-washer can be off. This ensures the washer is run at a
minimum interval even if the well level has not reached the activation level.
