15.2 Configuring the Setpoints of Profiles

To edit the setpoints of a profile, select that profile first by pressing the Switch Profile button in the
Level/Control Setpoints screen. This button only switches to that profile for editing purposes. See Section
12.3.2 for changing setpoints.
To switch to a different profile that is used by the station see Section 15.1.1.

15.3 Configuring Other Profile Properties

Profiles are configured through the Advanced menu:
From the tree select: Pump Control
•
Select the desired profile from the list and press
•
The following values can be set for each profile:
DIN Activation
•
Lead/Lag pump parameters
•
Timers
•
Name
•
The above values can only be set in the Advanced menu
Activation Delay
•
• Activation Set Point
Deactivation Delay
•
Deactivation Set Point
•
The setpoints and delays are best set by switching to that profile using the Switch Profile button (under
Settings -> Set Points -> Level/Control Setpoints) and edit as per the default profile.
Maximum Off Time Duration
•
Maximum Off Time Enabled?
•
Maximum Off Time Quantity
•
Maximum Pumps Running Mode
•
Maximum Pumps Running Quantity
•
Maximum (Pump) Run Time Duration
•
Maximum (Pump) Run Time Enabled?
•
These maximum values can be set under Station Optimization.
NOTE: Currently, if the unit is operating with the profile you are editing, to activate the new parameters
for this profile the unit needs to be switched out of the profile and back in, see Section 15.1.1 for how to
do this.
