7.2 Default Wiring Setup for Pump Control Board
While many different configurations of the MultiSmart are possible, four common configurations are
illustrated in this section.. These default configurations can be applied by completing the Setup Wizard in
the Settings menu. After a default configuration has been applied changes can be made as required. Refer
to Section 7.3 for a complete description of the Pump Control I/O Board.
7.2.1
Default 1 – 10 Sensor Probe and 2 Pumps
Figure 30 – Default 1
MultiSmart_IO_Manual_A4_v2-22_R15.doc
Page 33 of 201
