9.2 Setup Wizard Notes

9.2.1 Key Setup Wizard Parameters
While many of the parameters specified during the Setup Wizard can be modified (if necessary) at a later
date through other menus, some key setup parameters can only be changed through the Setup Wizard, so
it's important that these parameters are correct the first time.
The Setup Wizard can be run any number of times, but each time it clears the memory, such that any other
configuration changes are lost and must be re-entered (if still required). The key setup parameters are listed
below.
Key Setup Parameter
Station Type
Station Mode
Number of MultiSmart Units
Board in Bottom Slot
Number of Wells
Number of Pumps
Table 5 – Key Setup Parameters (can only be modified through the Setup Wizard)
9.2.2 Activating New Modules
Each MultiSmart unit comes with certain modules enabled. New modules are activated with a new site key.
New site keys can be entered at any time when new modules need to be activated.
9.2.3 Fill (Charge) or Empty (Discharge) Modes
A pump station can be configured to either Fill (Charge), or Empty (Discharge) the well.
9.2.4 Number of MultiSmart Units in Installation
Multiple MultiSmart units can be connected together using the CAN Bus interface. This allows additional I/O
to be added to the station if required. A "unit" is defined as a separate DIN mounted housing containing one
DSP Board and at least one other board (such as a 3PC Pump Control Board, for example).
9.2.5 Configuring the Type of Board Located in the Bottom Slot
There are four board slots in a MultiSmart unit. By setting what type of board is located in the bottom slot,
the setup wizard can determine the correct I/O configuration for the unit.
9.2.6 Number of Wells in Station
A station can have up to three wells.
9.2.7 Level Devices
There is a choice of Probe (MultiTrode conductive probe), DuoProbe (MultiTrode conductive probe with
pressure transducer, Analog (e.g. Pressure transducer or ultrasonic) or Remote Level. Remote level is
typically used where the pump station is pumping to a reservoir.
NOTE: If later it becomes necessary to change the level device, there is no need to go back through
the setup wizard, simply see Section 14.8.
Page 68 of 260
MultiSmart Installation & Operation Manual
Options
Pump Station, Reservoir, RTU
Fill, Empty
1-3
3PC, 3MP, None
1-3
1-9
