16.2 Additional Parameters

Pressing the Advanced button on the Optimization screen displays the advanced settings screen, where a
large number of additional pump control settings may be found, including the following settings.
16.2.1 Max. Number Groups Running
This feature is used to control how many groups run at same time. This function is only required when more
than one group has been configured. It can be used to restrict groups from running at the same time, for
example, making sure jockey pumps do not run when flood pumps are running. The feature is on by default
and set to 1.
16.2.2 Group
When more than one group of pumps have been configured (see Section 13.3), different parameters can be
set for each group. For example, Max Pumps Running can be set differently for group 1 and group 2.
16.2.3 Pulse Start & Pulse Stop
A digital input can be assigned to the Pulse Start option through the advanced menu. The example below
shows how to assign Digital Input 12 to Pulse Start:
•
From the tree select Pump Control
•
Scroll down to Source and press "Use this button to view or change value."
•
From within the Digital tag tree, scroll down to IO
•
Select the board that contains the Digital Input, in this case the Top Board
•
Scroll down to chosen digital input, (DIN.12 shown here) _12
•
Scroll down to a DigitalTag, select ValueDigital, press Ok, then press Save
•
Use the Back button to return to the main screen.
The pulse start function will normally only allow a pump to start if the level is above the pump's deactivation
point. An additional configuration parameter allows the Pulse Start and Pulse Stop feature to ignore the level.
This feature is configured by the parameter:
Once this configuration parameter is activated the Setpoints will be hidden both on the main display and in
the Settings menu option.
To activate the Digital Input a restart is required.
(Alternatively cycle the power).
Page 148 of 260
MultiSmart Installation & Operation Manual
(This is the direct path).
+ / -
Pulse Start
+ / -
Pulse Start 01
+ / - + / - + / -
Unit _1
+ / -
MultiSmart_IO_Manual_R20
+ / -
+ / - + / -
then Din
