FC 300 Design Guide
Bits 13/14, Set-up selection
Choose between the four parameter set-ups via
bits 13 and 14 according to the shown table:
The function is only possible if you choose Multi
Set-up in par. 0-10. The selection in par. 8-55
Set-up Select determines how bits 13 and 14
link with the corresponding function of the digital
inputs. When the motor is running, you can
only change the set-up if it is linked.
Bit 15, No function/Reverse
Reverse of the motor rotational direction. Bit 15 = "0": No reverse. Bit 15 = "1": Reverse. The reverse in
the default setting in par. 8-54 Reversing Select is "Logic OR". Bit 15 causes a reverse only when "Bus",
"Logic OR", or "Logic AND" is selected ("Logic AND" only in connection with terminal 9, however).
NOTE
Unless otherwise indicated, the control word bit links with the corresponding
digital input function as a logic "OR".
default setting ( ) display text
*
250
How to Program
[ ] value for use in communication via serial communication port
MG.33.B3.22 - VLT is a registered Danfoss trademark
Set-up Bit 13
1 0
2 1
3 0
4 1
Bit 14
0
0
1
1
