FC 300 Design Guide
0-** Operation/Display
"
Par. Parameter description
No. #
0-0* Basic settings
0-01 Language
0-04 Operating state at Power-up (Hand)
0-1* Set-up handling
0-10 Active set-up
0-11 Edit set-up
0-12 This set-up linked to
0-13 Readout: Linked set-ups
0-14 Readout: Edit set-ups / channel
0-2* LCP Display
0-20 Display line 1.1 small
0-21 Display line 1.2 small
0-22 Display line 1.3 small
0-23 Display line 2 large
0-24 Display line 3 large
0-25 My personal menu
0-4* LCP keypad
0-40 [Hand on] key on LCP
0-41 [Off] key on LCP
0-42 [Auto on] key on LCP
0-43 [Reset] key on LCP
0-5* Copy/Save
0-50 LCP copy
0-51 Set-up copy
0-6* Password
0-60 Main menu password
0-61 Access to main menu w/o password
0-64 Quick menu password
0-66 Access to quick menu w/o password
* default setting ( )
How to Program
display text [ ] value for use in communication via serial communication port
MG.33.B3.22 - VLT is a registered Danfoss trademark
Default value 4-set-up
[0] English 1 set-up
[1] Forced stop, ref=old All set-ups
[1] Setup 1 1 set-up
[1] Setup 1 All set-ups
[1] Setup 1 All set-ups
0 All set-ups
0 All set-ups
[1617] Speed (RPM) All set-ups
[1614] Motor current All set-ups
[1610] Power (kW) All set-ups
[1613] Frequency All set-ups
[1602] Reference % All set-ups
User depedent 1 set-up
[1] Enabled All set-ups
[1] Enabled All set-ups
[1] Enabled All set-ups
[1] Enabled All set-ups
[0] No copy All set-ups
[0] No copy All set-ups
100 1 set-up
[0] Full access 1 set-up
200 1 set-up
[0] Full access 1 set-up
Change Conver- Type
during sion index
operation
TRUE - Uint8
TRUE - Uint8
TRUE - Uint8
TRUE - Uint8
FALSE - Uint8
FALSE 0 Uint16
TRUE 0 Uint32
TRUE - Uint16
TRUE - Uint16
TRUE - Uint16
TRUE - Uint16
TRUE - Uint16
TRUE 0 Uint16
TRUE - Uint8
TRUE - Uint8
TRUE - Uint8
TRUE - Uint8
FALSE - Uint8
FALSE - Uint8
TRUE 0 Uint16
TRUE - Uint8
TRUE 0 Uint16
TRUE - Uint8
221
