FC 300 Design Guide
Select set-up 1 [2] - changes the active
•
set-up (par. 0-10) to "1".
• Select set-up 2 [3] - changes the active
set-up (par. 0-10) to "2".
Select set-up 3 [4] - changes the active
•
set-up (par. 0-10) to "3".
• Select set-up 4 [5] - changes the active set-up
(par. 0-10) to "4". If you change the set-up, it
will merge with other set-up commands coming
from either the digital inputs or via a fieldbus.
• Select preset reference 0 [10] - selects
preset reference 0.
Select preset reference 1 [11] - selects
•
preset reference 1.
• Select preset reference 2 [12] - selects
preset reference 2.
Select preset reference 3 [13] - selects
•
preset reference 3.
• Select preset reference 4 [14] - selects
preset reference 4.
Select preset reference 5 [15] - selects
•
preset reference 5.
• Select preset reference 6 [16] - selects
preset reference 6.
Select preset reference 7 [17] - selects preset
•
reference 7. If you change the active preset
reference, it will merge with other preset
reference commands coming from either the
digital inputs or via a fieldbus.
Select ramp 1 [18] - selects ramp 1.
•
Select ramp 2 [19] - selects ramp 2.
•
Select ramp 3 [20] - selects ramp 3.
•
Select ramp 4 [21] - selects ramp 4.
•
Run [22] - issues a start command to the drive.
•
Run reverse [23] - issues a start reverse
•
command to the drive.
Stop [24] - issues a stop command to the drive.
•
Qstop [25] - issues a quick stop command
•
to the drive.
• Dcstop [26] - issues a DC stop command
to the drive.
Coast [27] - the drive coasts immediately.
•
All stop commands including the coast
command stop the SLC.
Freeze output [28] - freezes the output
•
frequency of the drive.
Start timer 0 [29] - starts timer 0, see par.
•
13-20 for further description.
Start timer 1 [30] - starts timer 1, see par.
•
13-20 for further description.
default setting ( ) display text
*
204
How to Program
•
•
•
•
•
•
•
•
•
•
•
•
•
[ ] value for use in communication via serial communication port
MG.33.B3.22 - VLT is a registered Danfoss trademark
Start timer 2 [31] - starts timer 2, see par.
13-20 for further description.
Set digital output A low [32] - any output with
"digital output 1" selected is low (open).
Set digital output B low [33] - any output with
"digital output 2" selected is low (off).
Set digital output C low [34] - any output with
"digital output 3" selected is low (off).
Set digital output D low [35] - any output with
"digital output 4" selected is low (off).
Set digital output E low [36] - any output with
"digital output 5" selected is low (off).
Set digital output F low [37] - any output with
"digital output 6" selected is low (off).
Set digital output A high [38] - any output with
"digital output 1" selected is high (closed).
Set digital output B high [39] - any output with
"digital output 2" selected is high (closed).
Set digital output C high [40] - any output with
"digital output 3" selected is high (closed).
Set digital output D high [41] - any output with
"digital output 4" selected is high (closed).
Set digital output E high [42] - any output with
"digital output 5" selected is high (closed).
Set digital output F high [43] - any output with
"digital output 6" selected is high (closed).
