9-53 Profibus Warning Word
Option:
Bit: Meaning:
0 Connection with DP master is not
1 Timeout action active
2 FDL (Field-bus Data link Layer) is not ok
3 Clear data command received
4 Actual value is not updated
5 baud rate search
6 PROFIBUS ASIC is not transmitting
7 Initializing of PROFIBUS is not ok
8 drive is tripped
9 internal CAN error
10 wrong ID sent by PLC
11 Internal error occurred
12 not configured
13 clear command received
14 warning 34 active
Function:
Displays Profibus communication warnings.
9-63 Actual Baud Rate
Option:
Read-only
9.6 kbit/s
19.2 kbit/s
93.75 kbit/s
187.5 kbit/s
500 kbit/s
1500 kbit/s
3000 kbit/s
6000 kbit/s
12000 kbit/s
31.25 kbit/s
45.45 kbit/s
No baud rate found
Function:
Displays the actual PROFIBUS baud rate. The
Profibus Master automatically sets the baud rate.
9-64 Device Identification
Array [10]
* default setting ( ) display text
How to Program
The device identification parameter. The
data type is "Array[n] of Unsigned16". The
assignment of the first subindexes is defined
and shown in the table above.
[0]
[1]
[2]
[3]
[4]
[6]
Contains the profile identification. Byte 1
[7]
contains the profile number and byte 2 the
[8]
version number of the profile.
[9]
[10]
[11]
[255]
*
Parameter values changed via Profibus are not
automatically stored into non-volatile memory. Use
this parameter to activate a function that stores all
parameter values in the EEPROM. Thus, you retain
changed parameter values at power-down.
[ ] value for use in communication via serial communication port
MG.33.B3.22 - VLT is a registered Danfoss trademark
Option:
Read only
Array
Index Content
[0] manufacturer
[1] device type
[2] version
[3] firmware date year
[4] firmware date month
[5] no. of axes
[6] vendor specific :PB
Version
[7] vendor-specific :
Database Version
[8] vendor-specific :
AOC Version
[9] vendor-specific :
MOC Version
Function:
9-65 Profile Number
Option:
Read only
0 - 0
Function:
9-71 Save Data Values
Option:
Off
Store edit setup
Store all set-ups
Function:
[10]
Value
128 (for Danfoss)
1
xxyy
yyyy
ddmm
variable
xxyy
xxyy
xxyy
xxyy
*
0
[0]
[1]
[2]
