FC 300 Design Guide
Function:
Address selection for the FC (standard) port.
Valid range: 1 - 126.
8-32 FC Port Baud Rate
Option:
2400 Baud
4800 Baud
*
9600 Baud
19200 Baud
38400 Baud
115200 Baud
Function:
Baud rate selection for the FC (standard) port.
8-35 Minimum Response Delay
Range:
1 - 500 ms
Function:
Specifies a minimum delay time between receiving
a request and transmitting a response. This is used
for overcoming modem turnaround delays.
8-36 Max Response Delay
Range:
1 - 10000 ms
Function:
Specifies a maximum allowed delay time between
transmitting a request and expecting a response.
Exceeding this delay causes control word timeout.
8-37 Max Inter-Char Delay
Range:
0 - 30 ms
Function:
Maximum waiting time between two received bytes.
It ensures timeout, if transmission is interrupted.
Note: This is only enforced when the FC MC
protocol is selected in par. 8-30.
8-5* Digital/Bus
"
8-50 Coasting Select
Option:
Digital input
Bus
Logic AND
default setting ( ) display text
*
184
How to Program
*
Allows a choice between controlling the
coasting function via the terminals (digital
input) and/or via the bus.
[0]
[1]
[2]
[3]
[4]
[7]
*
*
10ms
Allows a choice between controlling the
Quick stop function via the terminals (digital
input) and/or via the bus.
*
5000ms
*
*
25ms
Allows a choice between controlling the DC brake
via the terminals (digital input) and/or via the bus.
[0]
[1]
*
[2]
[ ] value for use in communication via serial communication port
MG.33.B3.22 - VLT is a registered Danfoss trademark
Logic OR
Function:
NOTE
This parameter is active only when
par. 8-01 Control Site is set to [0]
Digital and control word.
8-51 Quick Stop Select
Option:
Digital input
Bus
Logic AND
Logic OR
Function:
NOTE
This parameter is active only when
par. 8-01 Control Site is set to [0]
Digital and control word.
8-52 DC Brake Select
Option:
Digital input
Bus
Logic AND
Logic OR
Function:
NOTE
This parameter is active only when
par. 8-01 Control Site is set to [0]
Digital and control word.
8-53 Start Select
Option:
Digital input
Bus
Logic AND
Logic OR
[3]
[0]
[1]
[2]
[3]
[0]
[1]
[2]
[3]
[0]
[1]
[2]
[3]
