FC 300 Design Guide
Digital input DI29
Digital input DI32
Digital input DI33
Start command
Drive stopped
Function:
The list describes the available Boolean (TRUE or
FALSE) input for use in the selected logic rule.
*False [0] (default setting) - enters the fixed
•
value of FALSE in the logic rule.
True [1] - enters the fixed value TRUE
•
in the logic rule.
Running [2] - see par. 5-13 for further
•
description.
In range [3] - see par. 5-31 for further
•
description.
On reference [4] - see par. 5-31 for
•
further description.
Torque limit [5] - see par. 5-31 for
•
further description.
Current limit [6] - see par. 5-31 for
•
further description.
Out of current range [7] - see par. 5-31
•
for further description.
• Below I low [8] - see par. 5-31 for
further description.
Above I high [9] - see par. 5-31 for
•
further description.
• Below frequency low [11] - see par. 5-31
for further description.
Above frequency high [12] - see par. 5-31
•
for further description.
• Thermal warning [16] - see par. 5-31
for further description.
Mains out of range [17] - see par. 5-31
•
for further description.
• Reverse [18] - see par. 5-31 for further
description.
Warning [19] - see par. 5-31 for further
•
description.
• Alarm (trip) [20] - see par. 5-31 for
further description.
Alarm (trip lock) [21] - see par. 5-31
•
for further description.
• Comparator 0 [22] - use the result of
comparator 0 in the logic rule.
Comparator 1 [23] - use the result of
•
comparator 1 in the logic rule.
default setting ( ) display text
*
196
How to Program
[36]
•
[37]
[38] •
[39]
[40]
•
•
•
•
•
•
•
•
•
•
[ ] value for use in communication via serial communication port
MG.33.B3.22 - VLT is a registered Danfoss trademark
Comparator 2 [24] - use the result of
comparator 2 in the logic rule.
Comparator 3 [25] - use the result of
comparator 3 in the logic rule.
Logic rule 0 [26] - use the result of logic
rule 0 in the logic rule.
Logic rule 1 [27] - use the result of logic
rule 1 in the logic rule.
Logic rule 2 [28] - use the result of logic
rule 2 in the logic rule.
Logic rule 3 [29] - use the result of logic
rule 3 in the logic rule.
Digital input DI18 [33] - use the value of DI18
in the logic rule (High = TRUE).
Digital input DI19 [34] - use the value of DI19
in the logic rule (High = TRUE).
Digital input DI27 [35] - use the value of DI27
in the logic rule (High = TRUE).
Digital input DI29 [36] - use the value of DI29
in the logic rule (High = TRUE).
Digital input DI32 [37] - use the value of DI32
in the logic rule (High = TRUE).
Digital input DI33 [38] - use the value of DI33
in the logic rule (High = TRUE).
13-02 Stop Event
Option:
FALSE
TRUE
Running
In range
On reference
Torque limit
Current limit
Out of current range
Below I low
Above I high
Below speed low
Above speed high
Out of feedb. range
Below feedb. low
Above feedb. high
Thermal warning
Mains out of range
Reverse
Warning
Alarm (trip)
Alarm (trip lock)
Comparator 0
[0]
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[11]
[12]
[13]
[14]
[15]
[16]
[17]
[18]
[19]
[20]
[21]
[22]
