Danfoss VLT AutomationDrive FC 300 Design Manual page 216

FC 300 Design Guide
16-33 Brake Energy /2 min
Range:
0.000 - 0.000 kW
Function:
Returns the brake power transmitted to an external
brake resistor. The mean power is calculated on
an average basis for the latest 120 s.
16-34 Heatsink Temp.
Range:
0 - 0 °C
Function:
States the drive heat sink temperature. The cut-out
limit is 90 ± 5 °C (194 ± 9 °F), while the unit
cuts back in at 60 ± 5 °C (140 ± 9 °F).
16-35 Inverter Thermal
Range:
0 - 0 %
Function:
Returns the percentage load of the inverters.
16-36 Inv. Nom. Current
Range:
0.01 - 100.00 A
Function:
The value should equal the nameplate data
on the connected motor. The data is used for
calculation of torque, motor protection etc.
Changing the value in this parameter affects
the setting of other parameters.
16-37 Inv. Max. Current
Range:
0.01 - 100.00 A
Function:
The value should equal the nameplate data
on the connected motor. The data is used for
calculation of torque, motor protection etc.
Changing the value in this parameter affects
the setting of other parameters.
16-38 SL Controller State
Range:
0 - 0
default setting ( ) display text
*
216
How to Program
Returns the state of which event the controller
is going to execute.
*
0.000kW
Returns the temperature on the control
card in degree °C.
*
0 °C
*
Returns if the Data Log is full (see par. 15-1).
The log will never fill when Logging Mode (see
par. 15-13) is set to Log always.
*
0 %
16-5* Ref. & Feedb.
"
*
A
Returns the total reference sum of digital/ana-
log/preset/bus/freeze ref./catch up and slow-down.
Returns the reference value from programmed
digital input(s). The readout can also be the
impulses from an incremental encoder.
*
A
Gives the resulting feedback value by means
of the unit/scaling selected in par. 3-00,
3-01, 3-02 and 3-03.
*
0
[ ] value for use in communication via serial communication port
MG.33.B3.22 - VLT is a registered Danfoss trademark
Function:
16-39 Control Card Temp.
Range:
0 - 0 °C
Function:
16-40 Logging Buffer Full
Option:
No
Yes
Function:
16-50 External Reference
Range:
0.0 - 0.0
Function:
16-51 Pulse Reference
Range:
0.0 - 0.0
Function:
16-52 Feedback [Unit]
Range:
0.0 - 0.0
Function:
*
0 °C
[0]
[1]
*
0.0
*
0.0
*
0.0
