FC 300 Design Guide
Bit 12, Relay 02:
Bit 12 = "0": Relay 2 is not activated. Bit 12 = "1": Relay 02 is activated provided
that Control word bit 12 is chosen in par. 5-40.
Bit 13/14, Selection of set-up:
Use bits 13 and 14 to choose from the four
menu set-ups according to the shown table. The
function is only possible when Multi Set-Ups is
selected in par. 0-10 Active Set-Up.
NOTE
Make a selection in par. 8-55
Set-up select to define how Bit
13/14 gates with the corresponding
function on the digital inputs.
Bit 15 Reverse:
Bit 15 = "0": No reverse Bit 15 = "1": Reverse. In the default setting, reverse is set to digital in par. 8-54
Reversing select. Bit 15 causes reverse only when Ser. communication, Logic or or Logic and is selected.
* default setting ( ) display text
How to Program
[ ] value for use in communication via serial communication port
MG.33.B3.22 - VLT is a registered Danfoss trademark
Set-up Bit 14
1 0
2 0
3 1
4 1
Bit 13
0
1
0
1
