FC 300 Design Guide
Control Word par. 16-00
Reference [Unit] par. 16-01
Reference % par. 16-02
Status Word par. 16-03
Power [kW] par. 16-10
Power [hp] par. 16-11
Motor Voltage par. 16-12
Frequency par. 16-13
Motor Current par. 16-14
Torque par. 16-16
Speed [RPM] par. 16-17
Motor thermal par. 16-18
KTY sensor temperature par. 16-19
Phase angle par. 16-20
DC Link Voltage par. 16-30
BrakeEnergy/s par. 16-30
BrakeEnergy/2 min par. 16-33
Heatsink temp. par. 16-34
Inverter thermal par. 16-35
SL Controller State par. 16-38
Controlcard temp. par. 16-39
External Reference par. 16-50
Pulse Reference par. 16-51
Feedback [Unit] par. 16-52
External Reference par. 16-53
Terminal 53 Switch Setting par. 16-63
Analog Input 53 par. 16-62
Terminal 54 Switch Setting par. 16-63
Analog Input 54 par. 16-64
Analog Output 42 [mA] par. 16-65
Digital Output [bin] par. 16-66
Freq. input #29 [Hz] par. 16-67
Freq. input #33 [Hz] par. 16-68
Pulse output #27 [Hz] par. 16-69
Pulse output #29 [Hz] par. 16-70
Comm Option STW par. 16-84
FC port CTW 1 par. 16-85
Alarm Word par. 16-90
Alarm Word 2 par. 16-91
Warning Word par. 16-92
Warning Word 2 par. 16-93
Extended Status Word par. 16-94
Extended Status Word 2 par. 16-95
Function:
Used for the pre-defined I/O assembly Instances.
Only 2 elements [1,2] of this array are used. All
elements are set to 0 as default.
* default setting ( ) display text
How to Program
Reads out warning messages via standard bus or
DeviceNet. This parameter is not available via LCP
but you can see the warning message by choosing
Com warning word as display readout. One bit is
assigned to every warning (see manual for list).
*
Enables selection of reference source in
Instance 21/71 and 20/70.
- Off: Enables reference via analog/digital inputs.
- On: Enables reference via the bus.
*
[ ] value for use in communication via serial communication port
MG.33.B3.22 - VLT is a registered Danfoss trademark
10-13 Warning Parameter
Range:
0 - 63
Function:
Bit: Meaning:
0 Bus not active
1 Explicit connection timeout
2 I/O connection
3 Retry limit reached
4 Actual is not updated
5 CAN bus off
6 I/O send error
7 Initialization error
8 No bus supply
9 Bus off
10 Error passive
11 Error warning
12 Duplicate MAC ID Error
13 RX queue overrun
14 TX queue overrun
15 CAN overrun
10-14 Net Reference
Option:
Read-only from LCP.
Off
On
Function:
10-15 Net Control
Option:
Read-only from LCP.
Off
On
*
63
[0]
[1]
[0]
[1]
