FC 300 Design Guide
How to Program
Bit 05, Not used:
Bit 05 is not used in the status word.
Bit 06, No error / triplock:
Bit 06 = "0": The adjustable frequency drive is not in fault mode. Bit 06 = "1": The
adjustable frequency drive is tripped and locked.
Bit 07, No warning/warning:
Bit 07 = "0": There are no warnings. Bit 07 = "1": A warning has occurred.
Bit 08, Speed≠ reference/speed = reference:
Bit 08 = "0": The motor is running but the present speed is different from the preset speed
reference. This might be the case e.g. when the speed ramps up/down during start/stop. Bit
08 = "1": The motor speed matches the preset speed reference.
Bit 09, Local operation/bus control:
Bit 09 = "0": [STOP/RESET] is activate on the control unit or Local control in par. 3-13 Reference site is
selected. You cannot control the adjustable frequency drive via serial communication. Bit 09 = "1": It is
possible to control the adjustable frequency drive via the fieldbus/ serial communication.
Bit 10, Out of frequency limit:
Bit 10 = "0": The output frequency has reached the value in par. 4-11 Motor speed low limit or par.
4-13 Motor speed high limit. Bit 10 = "1": The output frequency is within the defined limits.
Bit 11, No operation/in operation:
Bit 11 = "0": The motor is not running. Bit 11 = "1": The adjustable frequency drive has
a start signal or the output frequency is greater than 0 Hz.
Bit 12, Drive OK/stopped, autostart:
Bit 12 = "0": There is no temporary overheating in the inverter. Bit 12 = "1": The inverter stops because of
overheating but the unit does not trip and will resume operation once the overheating stops.
Bit 13, Voltage OK/limit exceeded:
Bit 13 = "0": There are no voltage warnings. Bit 13 = "1": The DC voltage in the adjustable
frequency drive's intermediate circuit is too low or too high.
Bit 14, Torque OK/limit exceeded:
Bit 14 = "0": The motor current is lower than the torque limit selected in par. 4-18 Current Limit.
Bit 14 = "1": The torque limit in par. 4-18 Current Limit is exceeded.
Bit 15, Timer OK/limit exceeded:
Bit 15 = "0": The timers for motor thermal protection and VLT thermal protection are not
exceeded 100%. Bit 15 = "1": One of the timers exceeds 100%.
* default setting ( ) display text [ ] value for use in communication via serial communication port
